Customized Industrial Servo Motor 4.4KW Rated Output With Straight Shaft End SGMGV-44ADA21

Product Categories
Shenzhen Wisdomlong Technology CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Customized Industrial Servo Motor 4.4KW Rated Output With Straight Shaft End SGMGV-44ADA21

  • 1
  • 2
  • 3

Brand Name : Yaskawa

Model Number : SGMGV-44ADA21

Place of Origin : Japan

MOQ : 1

Price : negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100

Delivery Time : 2-3 work days

Packaging Details : New in original box

Brand : Yaskawa

Model : SGMGV-44ADA21

Type : AC SERVO MOTOR

Power : 4.4KW

Volatge : 200V

Current : 32.8A

Ins : F

Contact Now

Industrial Servo Motor Yaskawa Servo Motor SGMGV-44ADA21 4.4KW 32.8A
Specifications
Description SGMGV-44ADA21 is a Motors-AC Servo produced by Yaskawa
Servomotor Type SGMGV Sigma V High-torque type
Rated Output 4.4KW
Rated Current 32.8A
2.8N.m
1500r/min
Ins F
Power Supply Voltage 200VAC
Serial Encoder 20-bit Incremental
Design Revision Order Standard
Shaft End Straight with key and tap
Options Without options
Control Standard
  • Model Number:SGMGV-09ADA61
  • Power Supply:DC
  • Motor Type:Amplifier
  • is_customized:yes
  • Install Style:Plug-in
  • Frequency:High Frequency
  • Function:Power Triode
  • Construction:Point Contact Type
  • Structure:PNP
  • Type:Amplifier
  • Special Function:Common Point Contact Diode
  • Usage:Light-emitting Diode



SIMILAR PRODUCTS

SGMGV-1AA3A6C
SGMGV-1AA3A6E
SGMGV-1AA3A6S
SGMGV-1EA3A61
SGMGV-1EA3A6C
SGMGV-1EA3A6E
SGMGV-1EA3A6S
SGMGV-03ADA61
SGMGV-03ADA6C
SGMGV-03ADA6E
SGMGV-03ADA6S
SGMGV-05ADA61
SGMGV-05ADA6C
SGMGV-05ADA6E
SGMGV-05ADA6S
SGMGV-09ADA61
SGMGV-09ADA6C
SGMGV-09ADA6E
SGMGV-09ADA6S
SGMGV-13ADA61
SGMGV-13ADA6C
SGMGV-13ADA6E
SGMGV-13ADA6S
SGMGV-20ADA61
SGMGV-20ADA6C
SGMGV-20ADA6E
SGMGV-20ADA6S
SGMGV-30ADA61

Customized Industrial Servo Motor 4.4KW Rated Output With Straight Shaft End SGMGV-44ADA21
: These items and torque-motor speed characteristics quoted in combination with a SERVOPACK are at an armature winding temperature of 20˚C. Notes: 1 The values in parentheses are for servomotors with holding brakes. 2 The above specifications show the values under the cooling condition when the following heat sinks are mounted on the servomotors. SGMGV-03D/-05D: 250 mm × 250 mm × 6 mm (aluminum) SGMGV-09D/-13D/-20D: 400 mm × 400 mm × 20 mm (iron) SGMGV-30D/-44D/-55D/-75D: 550 mm × 550 mm × 30 mm (iron) SGMGV-1AD/-1ED: 650 mm × 650 mm × 35 mm (iron)
Separate the servomotor main circuit cable wiring from the I/O signal cable and encoder cable at least 30 cm, and do not bundle or run them in the same duct. x When the main circuit cable length exceeds 20 m, note that the intermittent duty zone of the Torque-Motor Speed Characteristics will shrink as the line-to-line voltage drops.
Customized Industrial Servo Motor 4.4KW Rated Output With Straight Shaft End SGMGV-44ADA21
Notes: 1 Servomotor-end connectors (receptacles) are RoHS-compliant. Contact the respective connector manufacturers for RoHS-compliant cable-end connectors (not provided by Yaskawa). 2 Servomotor-end connectors (receptacles) can be used with MS plugs. For the model number of the MS receptacle, refer to the receptacle number in parentheses and select the appropriate plug.
Customized Industrial Servo Motor 4.4KW Rated Output With Straight Shaft End SGMGV-44ADA21
0.85 to 15 kW servomotors require servomotor-end connector and brake power supply connector. The servomotor-end connector is the same as is used for servomotors without holding brakes.
To order a brake power supply connecter kit (0.85 to 15 kW) with the order no. below, contact your Yaskawa representative. Connector Type S: Straight plug A: L-shaped plug Bush Size*1 S : Size S (4.0 dia. to 6.0 dia.) M : Size M (6.0 dia. to 9.0 dia.) L : Size L (9.0 dia. to 11.6 dia.) Contact Pin Size S2: Soldered C3: Crimped type*2 *1: A size-M connector kit is available as a standard equipment. *2: A crimp tool (model: 357J-50448T) by DDK Ltd. is required.
